LibreNMS Alerts

An overview of LibreNMS alerts used to monitor different anomalies.

RPKI Session down – JUNOS

Trigger alert if we logged a RPKI session has gone down within the last 1 hour. Match based on syslog events from device. (Device > log > syslog)

syslog.msg LIKE '%RPD_RV_SESSIONDOWN%'
AND syslog.timestamp >= macros.past_60m
AND macros.device_up = 1

Broadcast packets exceeds threshold – JUNOS

Trigger alert if more than 300 broadcast pkt/s on 10/25/100 GbE interfaces. ifAlias (interface description on the network device) needs to begin with “PEERING”.

ports_statistics.ifInBroadcastPkts_rate > 300
AND ports.ifAlias LIKE 'PEERING%'
AND macros.device_up = 1
AND (
  ports.ifName LIKE 'et-%'
  OR ports.ifName LIKE 'xe-%'
)

RouterOS Script: Check Google Global Cache Cluster

Open the built-in editor

/system/script/edit value-name=source check-ggc-cluster

Paste the script content

:global currentGGCcluster;

:local result;
:local data;
:local newGGCcluster;

:set result [/tool/fetch output=user url="https://redirector.googlevideo.com/report_mapping?di=no" as-value ascii=yes];
:set data [:tostr [:pick $result [:find $result "="] [:find $result ";"]]];
:set newGGCcluster [:tostr [:pick $data ([:find $data ">"] + 2) [:len $data]]];

:if ($newGGCcluster != $currentGGCcluster) do={
    :put "SP GGC Cluster $currentGGCcluster changed to $newGGCcluster";
    :set currentGGCcluster $newGGCcluster;
    /log info "SP GGC Cluster $currentGGCcluster changed to $newGGCcluster";
}

Add the scheduler (policy not restricted, probably should be)

/system/scheduler/add interval=1d name=check-ggc-cluster on-event="/system/script/run check-ggc-cluster;" policy=ftp,reboot,read,write,policy,test,password,sniff,sensitive,romon start-time=startup

Check variable contents

/system/script/environment/print detail where name=currentGGCcluster

Add Danish NemID X.509 public certificate to RIPE Database

General

If you ever used the RIPE Database.

You know the following RIPE Maintainer Authentication methods is possible.

  1. SSO (a.k.a. single sign on)
  2. key-cert (GnuPG keys + X.509 certificate)
  3. MD5 encrypted passwords

NemID

  1. IF you have the danish NemID follow the guidelines here to configure NemID on your computer. And then for you email program.
  2. Go find your public certificate here and download it.
  3. Open the certificate locally on your computer and prepend every line with ‘certif: ‘ so it looks the example below. Remember the key-value pairs:
    • key-cert: auto
    • mnt-by: xyz
    • source: ripe

Example

  • from older RIPE documentation.
key-cert: AUTO-1
certif: -----BEGIN CERTIFICATE-----
certif: MIID8zCCA1ygAwIBAgICAIIwDQYJKoZIhvcNAQEEBQAwcTELMAkGA1UEBhMCRVUx
certif: EDAOBgNVBAgTB0hvbGxhbmQxEDAOBgNVBAoTB25jY0RFTU8xHTAbBgNVBAMTFFNv
certif: ZnR3YXJlIFBLSSBUZXN0aW5nMR8wHQYJKoZIhvcNAQkBFhBzb2Z0aWVzQHJpcGUu
certif: bmV0MB4XDTAzMDkwODEwMjYxMloXDTA0MDkwNzEwMjYxMlowfTELMAkGA1UEBhMC
certif: TkwxETAPBgNVBAoTCFJJUEUgTkNDMRAwDgYDVQQLEwdNZW1iZXJzMRgwFgYDVQQD
certif: Ew91ay5idC50ZXN0LXVzZXIxLzAtBgkqhkiG9w0BCQEWIHRlc3QtdXNlckBsaW51
certif: eC50ZXN0bGFiLnJpcGUubmV0MIIBIjANBgkqhkiG9w0BAQEFAAOCAQ8AMIIBCgKC
certif: AQEArv3srxyl1QA3uS4dxdZbSsGrfBrMRjMb81Gnx0nqa6i+RziIf13lszB/EYy0
certif: PgLpQFdGLdhUQ52YsiGOUmMtnaWNHnEJrBUc8/fdnA6GVdfF8AEw1PTfJ6t2Cdc9
certif: 2SwaF+5kCaUDwmlOgbM333IQmU03l3I1ILs32RpQyZ+df/ovHNrVzeLc2P59isac
certif: bfjM2S0SXPQzHjuVLH40eOgVuXA/5LAYs51eXqwtKszSxFhqekf+BAEcRDrXmIT4
certif: e3zfiZOsXKe0UfaEABgHUMrYjsUCJ8NTMg6XiVSNwQQmXCdUbRvK7zOCe2iCX15y
certif: 9hNXxhY/q/IW54W5it7jGXq/7wIDAQABo4IBCDCCAQQwCQYDVR0TBAIwADARBglg
certif: hkgBhvhCAQEEBAMCBaAwCwYDVR0PBAQDAgXgMBoGCWCGSAGG+EIBDQQNFgtSSVBF
certif: IE5DQyBDQTAdBgNVHQ4EFgQUzdajNaRorkDTAW5O6Hpa3z9pP3AwgZsGA1UdIwSB
certif: kzCBkIAUHpLUfvaBVfxXVCcT0kh9NJeH7ouhdaRzMHExCzAJBgNVBAYTAkVVMRAw
certif: DgYDVQQIEwdIb2xsYW5kMRAwDgYDVQQKEwduY2NERU1PMR0wGwYDVQQDExRTb2Z0
certif: d2FyZSBQS0kgVGVzdGluZzEfMB0GCSqGSIb3DQEJARYQc29mdGllc0ByaXBlLm5l
certif: dIIBADANBgkqhkiG9w0BAQQFAAOBgQByg8L8RaiIz5k7n5jVwM/0oHSf48KRMBdn
certif: YdN2+eoEjVQbz48NtjbBTsOiUYj5AQWRHJrKtDQ+odbog0x7UsvhXjjBo/abJ6vI
certif: AupjnxP3KpSe73zmBUiMU8mvXLibPP1xuI2FPM70Y7fgeUehbmT7wdgqs7TEtYww
certif: PeUqjPPTZg==
certif: -----END CERTIFICATE-----
mnt-by: YOUR-MNT
source: RIPE

Afterwards you should be able to sign emails send to “RIPE Database” <auto-dbm@ripe.net> with your NemID certificate and the updates gets approved if your maintainer has authorization over the object you try to create/modify/delete.



My X.509 certificate
